RPMC Lasersについて

1996年にLDX Optronics (別LDメーカー)の販売サポートの目的で設立されました。
現在は他社品のリセールも行っており、カスタム品にも対応可能です。
LDX_9mm_SMAMM-laser-diodes_Free-spaceLDX Red Bar



製品 – products



LDX Laser Diodes

製品名 製品名
Multimode Laser Diodes Laser Diode Bars and Stacks


inquiry_button

Multimode Laser Diodes (PDF)

Free space

MM-laser-diodes_Free-spaceWide range from 445nm to 1.8um.

The Standard Package is the C-mount. Other Packages are available at additional cost (see list in the PDF above, and corresponding pictures in the Packages chapter).

  • 445-690nm:
Part Number Wavelength
(nm)
Output
Power
(mW)
Emitter
Size
(um)
Operating
Temp (°C)
Threshold
Current
(mA) Typ.
Operating
Current
(mA) Typ.
Operating
Voltage
(V) Typ.
Beam Divergence
(FWHM)
Spectral
Width (°)
FWHM
Polari
zation
θ// (°) θ٣ (°)
LDX-3102-445 445 ±10 nm 1,000 20 25 300 1,200 5 12° Full
Angle (1/e2 )
40° Full
Angle (1/e2 )
2 TE
LDX-2106-622 622 ±3 nm 150 60 5 750 1,250 2.3 7 50 1 TE
LDX-2205-627 627 ±3 nm 250 50 10 450 1,000 2.3 7 50 1 TE
LDX-2310-627 627 ±3 nm 350 100 10 900 1500 2.3 7 50 1 TE
LDX-2205-630 630 ±3 nm 250 50 15 450 1000 2.1 7 34 1 TM
LDX-2410-630 630 ±3 nm 400 100 15 900 1500 2.1 7 34 1 TM
LDX-2306-635 635 ±3 nm 300 60 15 425 800 2.4 7 34 1 TM
LDX-2410-635 635 ±3 nm 400 100 20 550 850 2.1 7 34 1 TM
LDX-2615-635 635 ±3 nm 600 150 20 600 1200 2.1 7 34 1 TM
LDX-3130-635 635 ±3 nm 1,200 300 15 1200 2900 2.2 7 34 1 TM
LDX-2205-645 645 ±3 nm 250 50 20 375 600 2.1 7 34 1 TE
LDX-2410-645 645 ±3 nm 400 100 20 500 1050 2.1 7 24 1 TE
LDX-3115-650 650 ±5 nm 1,000 150 20 700 1700 2.1 7 40 1 TE
LDX-2305-660 660 ±3 nm 300 50 20 300 700 2.1 7 40 1 TE
LDX-2710-660 660 ±3 nm 700 100 20 600 1150 2.1 7 40 1 TE
LDX-3115-660 660 ±3 nm 1,000 150 20 800 1550 2.2 7 40 1 TE
LDX-3230-660 660 ±3 nm 2,000 300 20 1800 3600 2.2 7 40 1 TE
LDX-2305-665 665 ±3 nm 300 50 20 300 900 2.1 7 40 1 TE
LDX-2710-665 665 ±3 nm 700 100 20 500 1350 2.1 7 40 1 TE
LDX-3115-665 665 ±3 nm 1,000 150 20 700 1600 2.1 7 40 1 TE
LDX-3230-665 665 ±3 nm 1,600 300 20 2000 4000 2.1 7 40 1 TE
LDX-2405-680 680 ±3 nm 400 50 20 300 900 2.1 7 40 1 TE
LDX-2710-680 680 ±3 nm 750 100 20 450 1350 2.1 7 40 1 TE
LDX-3115-680 680 ±3 nm 1,000 150 20 650 1600 2.1 7 40 1 TE
LDX-3230-680 680 ±3 nm 1,800 300 20 2000 4200 2.1 7 40 1 TE
LDX-2405-690 690 ±3 nm 400 50 20 300 900 2.2 7 34 1 TE
LDX-2710-690 690 ±3 nm 750 100 20 450 1100 2.2 7 34 1 TE
LDX-3115-690 690 ±3 nm 1,100 150 20 650 1600 2.2 7 34 1 TE







  • 730-885nm:
Part Number Wavelength
(nm)
Output
Power
(mW)
Emitter
Size
(um)
Operating
Temp (°C)
Threshold
Current
(mA) Typ.
Operating
Current
(mA) Typ.
Operating
Voltage
(V) Typ.
Beam Divergence
(FWHM)
Spectral
Width (°)
FWHM
Polari
zation
θ// (°) θ٣ (°)
LDX-3215-735 735 ±5 nm 2,000 150 20 600 1800 1.9 6 26 1 TM
LDX-3430-735 735 ±5 nm 4,000 300 20 180 5200 1.9 6 26 1 TM
LDX-3110-750 750 ±5 nm 1,500 100 20 400 1600 1.9 6 26 1 TM
LDX-3315-750 750 ±5 nm 3,000 150 25 500 3300 1.9 6 26 1.5 TM
LDX-3530-750 750 ±5 nm 5,000 300 20 180 5600 1.9 6 26 1.5 TM
LDX-3215-760 760 ±5 nm 2,000 150 20 500 2100 1.9 6 26 1 TM
LDX-3630-760 760 ±5 nm 6,000 300 20 200 6200 1.2 6 26 1 TM
LDX-3105-780 780 ±5 nm 1,200 50 20 300 1250 1.9 7 26 1 TM
LDX-3210-780 780 ±5 nm 2,000 100 20 400 2025 1.9 7 26 1 TM
LDX-3315-780 780 ±5 nm 3,000 150 20 800 2800 1.9 7 26 1 TM
LDX-3315-792 792 ±5 nm 3,000 150 25 500 2900 1.9 7 26 1.5 TM
LDX-3105-808 808 ±3 nm 1,200 50 20 300 1350 1.9 7 36 1 TE
LDX-3210-808 808 ±3 nm 2,000 100 20 300 2000 1.9 7 36 1.5 TE
LDX-3415-808 806 ±3 nm 4,000 150 20 370 3700 2.0 7 36 2 TE
LDX-3620-808 808 ±3 nm 6,000 200 20 1200 8500 1.8 7 27 2 TE
LDX-3740-808 808 ±3 nm 7,000 400 20 950 7100 2.0 7 36 1.5 TE
LDX-3820-808 808 ±3 nm 8,000 200 20 1200 8500 1.8 7 27 2 TM
LDX-3110-830 830 ±5 nm 1,600 100 20 250 1600 1.9 7 40 2 TE
LDX-3105-860 860 ±10 nm 1,000 50 20 150 1000 1.9 7 44 2 TE
LDX-3110-860 860 ±10 nm 1,600 100 20 200 1500 1.9 7 40 2 TE
LDX-3215-860 860 ±10 nm 2,500 150 20 350 2500 1.9 7 44 2 TE
LDX-3320-860 860 ±10 nm 3,300 200 20 450 3300 1.9 7 44 2 TE
LDX-3425-860 860 ±10 nm 4,200 250 20 550 4200 1.9 7 44 2 TE
LDX-3530-860 860 ±10 nm 5,000 300 20 650 5000 1.9 7 44 2 TE
LDX-3535-860 860 ±10 nm 5,800 350 20 750 5800 1.9 7 44 2 TE
LDX-3640-860 860 ±10 nm 6,600 400 20 850 6600 1.9 7 44 2 TE
LDX-3210-885 885 ±10 nm 2,500 100 20 200 2100 2.0 7 44 2 TE
LDX-3515-885 885 ±10 nm 5,000 150 20 350 4600 2 7 44 2 TE



  • 900-1850nm:
Part Number Wavelength
(nm)
Output
Power
(mW)
Emitter
Size
(um)
Operating
Temp (°C)
Threshold
Current
(mA) Typ.
Operating
Current
(mA) Typ.
Operating
Voltage
(V) Typ.
Beam Divergence
(FWHM)
Spectral
Width (°)
FWHM
Polari
zation
θ// (°) θ٣ (°)
LDX-3210-900 900 ±5 nm 2,000 100 20 200 2100 1.9 7 44 2 TE
LDX-3310-915 915 ±10 nm 3,000 100 20 250 2800 1.8 7 26 2 TE
LDX-3515-915 915 ±10 nm 5,000 150 20 400 5000 1.9 7 26 2 TE
LDX-3310-940 940 ±10 nm 3,000 100 20 250 2800 1.8 7 26 2 TE
LDX-3515-940 940 ±10 nm 5 000 150 20 400 5000 1.8 7 26 2 TE
LDX-3105-980 980 ±10 nm 1,500 50 20 200 1900 1.8 7 26 2 TE
LDX-3310-980 980 ±10 nm 3,000 100 20 250 3400 1.8 7 26 2 TE
LDX-3515-980 980 ±10 nm 5,000 150 20 400 5000 1.8 7 26 2 TE
LDX-3105-1064 1064 ±10 nm 1,500 50 25 500 1900 1.4 7 38 3 TE
LDX-3310-1064 1064 ±10 nm 3,000 100 20 300 3700 1.4 7 38 3 TE
LDX-3515-1064 1064 ±10 nm 5,000 150 20 500 7000 1.8 7 38 3 TE
LDX-3105-1120 1120 ±20 nm 1,200 50 20 250 2000 1.7 7 28 2 TE
LDX-3210-1120 1120 ±20 nm 2,500 100 20 300 4000 1.7 7 28 2 TE
LDX-3415-1120 1120 ±20 nm 4,000 150 20 450 6500 1.7 7 28 2 TE
LDX-3105-1210 1210 ±10 nm 1,200 50 20 900 4200 1.5 7 28 3 TE
LDX-3210-1210 1210 ±10 nm 2,000 100 20 900 7500 1.5 7 28 3 TE
LDX-3115-1350 1350 ±20 nm 1,500 150 20 900 7000 1.4 7 38 4 TE
LDX-3310-1350 1350 ±20 nm 3,500 100 20 320 6600 1.55 7 38 7 TE
LDX-3510-1350 1350 ±20 nm 5,000 100 20 450 10800 1.55 7 38 8 TE
LDX-3209-1450 1450 ±20 nm 2,500 95 20 500 4900 1.7 8 30 8 TE
LDX-3509-1470 1470 ±20 nm 5,000 95 20 500 9000 1.5 8 30 8 TE
LDX-3715-1470 1470 ±20 nm 7,000 150 20 800 16000 1.5 8 30 8 TE
LDX-3820-1470 1470 ±20 nm 8,000 200 20 800 18000 1.6 8 30 8 TE
LDX-3925-1470 1470 ±20 nm 9,000 250 20 800 21500 1.4 8 30 8 TE
LDX-2803-1550 1550 ±20 nm 800 35 20 800 3000 1.3 8 30 8 TE
LDX-3105-1550 1550 ±20 nm 1,000 50 20 800 3800 1.3 8 30 8 TE
LDX-3209-1550 1550 ±20 nm 2,500 95 20 500 6000 1.5 8 30 8 TE
LDX-3309-1550 1550 ±20 nm 3,500 95 20 500 9000 1.5 8 30 9 TE
LDX-3110-1550 1550 ±20 nm 1,200 100 20 800 5500 1.2 8 30 8 TE
LDX-3210-1550 1550 ±20 nm 2,000 100 20 800 9000 1.2 8 30 8 TE
LDX-3518-1550 1550 ±20 nm 5,000 180 20 800 14000 1.3 8 30 8 TE
LDX-2815-1620 1620 ±20 nm 800 150 20 900 5100 1.1 7 40 6 TE
LDX-3110-1850 1850 ±30 nm 1,000 100 20 400 5000 1.2 6 40 8 TE



inquiry_button

Fiber coupled

Wavelengths available from 445nm – 1.8um.

Hereunder are some standards examples, please ask for other specifications.

   MM-laser-diodes_14_pin_butterfly_package   LDX_9mm_SMA

  • 445-690nm:
Part Number Wavelength
(nm)
Output from Fiber Typ (mW) Min Fiber Size HHL & BTF (um) Min Fiber Size 9mm SMA (um) Operating Temp (°C) Threshold Current (mA) Typ. Operating Current (mA) Typ. Operating Voltage (V) Typ. Spectral Width (°) FWHM Polarization
LDX-3102-445-FC 445±10nm 700 100 200 25 300 1200 5 2 TE
LDX-2106-622-FC 622±3nm 105 100 200 5 750 1250 2.3 1 TE
LDX-2205-627-FC 627±3nm 175 100 200 10 450 1000 2.3 1 TE
LDX-2310-627-FC 627±3nm 245 100 250 10 900 1500 2.3 1 TE
LDX-2205-630-FC 630±3nm 175 100 200 15 450 1000 2.1 1 TM
LDX-2410-630-FC 630±3nm 280 100 250 15 900 1500 2.1 1 TM
LDX-2306-635-FC 635±3nm 210 100 200 15 425 800 2.4 1 TM
LDX-2410-635-FC 635±3nm 280 100 250 20 550 850 2.1 1 TM
LDX-2615-635-FC 635±3nm 420 200 300 20 600 1200 2.1 1 TM
LDX-3130-635-FC 635±3nm 840 400 600 15 1200 2900 2.2 1 TM
LDX-2205-645-FC 645±3nm 175 100 200 20 375 600 2.1 1 TE
LDX-2410-645-FC 645±3nm 280 100 250 20 500 1050 2.1 1 TE
LDX-3115-650-FC 650±5nm 700 200 300 20 700 1700 2.1 1 TE
LDX-2305-660-FC 660±3nm 210 100 200 20 300 700 2.1 1 TE
LDX-2710-660-FC 660±3nm 490 100 250 20 600 1150 2.1 1 TE
LDX-3115-660-FC 660±3nm 700 200 300 20 800 1550 2.2 1 TE
LDX-3230-660-FC 660±3nm 1400 300 450 20 1800 3600 2.2 1 TE
LDX-2305-665-FC 665±3nm 210 100 200 20 300 900 2.1 1 TE
LDX-2710-665-FC 665±3nm 490 100 250 20 500 1350 2.1 1 TE
LDX-3115-665-FC 665±3nm 700 200 300 20 700 1600 2.1 1 TE
LDX-3230-665-FC 665±3nm 1400 300 450 20 1800 3800 2.1 1 TE
LDX-2405-680-FC 680±3nm 280 100 200 20 300 900 2.1 1 TE
LDX-2710-680-FC 680±3nm 525 100 250 20 450 1350 2.1 1 TE
LDX-3115-680-FC 680±3nm 700 200 300 20 650 1600 2.1 1 TE
LDX-3230-680-FC 680±3nm 1260 300 450 20 2000 4200 2.1 1 TE
LDX-2405-690-FC 690±3nm 280 100 200 20 300 900 2.2 1 TE
LDX-2710-690-FC 690±3nm 525 100 250 20 450 1100 2.2 1 TE
LDX-3115-690-FC 690±3nm 770 200 300 20 650 1600 2.2 1 TE



  • 730-885nm:
Part Number Wavelength
(nm)
Output from Fiber Typ (mW) Min Fiber Size HHL & BTF (um) Min Fiber Size 9mm SMA (um) Operating Temp (°C) Threshold Current (mA) Typ. Operating Current (mA) Typ. Operating Voltage (V) Typ. Spectral Width (FWHM) Polarization
LDX-3215-735-FC 735±5nm 1,400 200 300 20 600 1800 1.9 1 TM
LDX-3430-735-FC 735±5nm 2,800 300 450 20 1800 5200 1.9 1 TM
LDX-3110-750-FC 750±5nm 1,050 100 250 20 400 1600 1.9 1 TM
LDX-3315-750-FC 750±5nm 2,100 200 300 25 500 3300 1.9 1.5 TM
LDX-3530-750-FC 750±5nm 3,500 300 450 20 1800 5600 1.9 1.5 TM
LDX-3215-760-FC 760±5nm 1,400 200 300 20 500 2100 1.9 1 TM
LDX-3630-760-FC 760±5nm 4,200 300 450 20 2000 6200 1.2 1 TM
LDX-3105-780-FC 780±5nm 840 100 200 20 300 1250 1.9 1 TM
LDX-3210-780-FC 780±5nm 1,400 100 250 20 400 2025 1.9 1 TM
LDX-3315-780-FC 780±5nm 2,100 200 300 20 800 2800 1.9 1 TM
LDX-3315-792-FC 792±5nm 2,100 200 300 25 500 2900 1.9 1.5 TM
LDX-3105-808-FC 808±3nm 840 100 200 20 300 1350 1.9 1 TE
LDX-3210-808-FC 808±3nm 1,400 100 250 20 300 2000 1.9 1.5 TE
LDX-3415-808-FC 806±3nm 2,800 200 300 20 370 3700 2 2 TE
LDX-3620-808-FC 808±3nm 4,200 200 400 20 1200 8500 1.8 2 TE
LDX-3740-808-FC 808±3nm 4,900 400 N/A 20 950 7100 2 1.5 TE
LDX-3820-808-FC 808±3nm 5,600 200 N/A 20 1200 8500 1.8 2 TM
LDX-3110-830-FC 830±5nm 1,120 100 250 20 250 1600 1.9 2 TE
LDX-3105-860-FC 860±10nm 700 100 200 20 150 1000 1.9 2 TE
LDX-3110-860-FC 860±10nm 1,120 100 250 20 200 1500 1.9 2 TE
LDX-3215-860-FC 860±10nm 1,750 200 300 20 350 2500 1.9 2 TE
LDX-3320-860-FC 860±10nm 2,310 200 350 20 450 3300 1.9 2 TE
LDX-3425-860-FC 860±10nm 2,940 400 400 20 550 4200 1.9 2 TE
LDX-3530-860-FC 860±10nm 3,500 400 N/A 20 650 5000 1.9 2 TE
LDX-3535-860-FC 860±10nm 4,060 400 N/A 20 750 5800 1.9 2 TE
LDX-3640-860-FC 860±10nm 4,620 400 N/A 20 850 6600 1.9 2 TE
LDX-3210-885-FC 885±10nm 1,750 100 250 20 200 2100 2 2 TE
LDX-3515-885-FC 885±10nm 3,500 200 N/A 20 350 4600 2 2 TE



  • 900-1850nm:
Part Number Wavelength
(nm)
Output from Fiber Typ (mW) Min Fiber Size HHL & BTF (um) Min Fiber Size 9mm SMA (um) Operating Temp (°C) Threshold Current (mA) Typ. Operating Current (mA) Typ. Operating Voltage (V) Typ. Spectral Width (FWHM) Polarization
LDX-3210-900-FC 900±5nm 1,400 100 250 20 200 2100 1.9 2 TE
LDX-3310-915-FC 915±10nm 2,100 100 250 20 250 2800 1.8 2 TE
LDX-3515-915-FC 915±10nm 3,500 200 300 20 400 5000 1.9 2 TE
LDX-3310-940-FC 940±10nm 2,100 100 250 20 250 2800 1.8 2 TE
LDX-3515-940-FC 940±10nm 3,500 200 300 20 400 5000 1.8 2 TE
LDX-3105-980-FC 980±10nm 1,050 100 200 20 200 1900 1.8 2 TE
LDX-3310-980-FC 980±10nm 2,100 100 250 20 250 3400 1.8 2 TE
LDX-3515-980-FC 980±10nm 3,500 200 300 20 400 5000 1.8 2 TE
LDX-3105-1064-FC 1064±10nm 1,050 100 200 25 500 1900 1.4 3 TE
LDX-3310-1064-FC 1064±10nm 2,100 100 250 20 300 3700 1.4 3 TE
LDX-3515-1064-FC 1064±10nm 3,500 200 300 20 500 7000 1.8 3 TE
LDX-3105-1120-FC 1120±20nm 840 100 200 20 250 2000 1.7 2 TE
LDX-3210-1120-FC 1120±20nm 1,750 100 250 20 300 4000 1.7 2 TE
LDX-3415-1120-FC 1120±20nm 2,800 200 300 20 450 6500 1.7 2 TE
LDX-3105-1210-FC 1210±10nm 840 100 200 20 900 4200 1.5 3 TE
LDX-3210-1210-FC 1210±10nm 1,400 100 250 20 900 7500 1.5 3 TE
LDX-3115-1350-FC 1350±20nm 1,050 200 300 20 900 7000 1.4 4 TE
LDX-3310-1350-FC 1350±20nm 2,450 200 250 20 320 6600 1.55 7 TE
LDX-3510-1350-FC 1350±20nm 3,500 200 250 20 450 10800 1.55 8 TE
LDX-3209-1450-FC 1450±20nm 1,750 200 250 20 500 4900 1.7 8 TE
LDX-3509-1470-FC 1470±20nm 3,500 100 N/A 20 500 9000 1.5 8 TE
LDX-3715-1470-FC 1470±20nm 4,900 * N/A 20 800 16000 1.5 8 TE
LDX-3820-1470-FC 1470±20nm 5,600 * N/A 20 800 18000 1.6 8 TE
LDX-3925-1470-FC 1470±20nm 6,300 * N/A 20 800 21500 1.4 8 TE
LDX-2803-1550-FC 1550±20nm 560 100 200 20 800 3000 1.3 8 TE
LDX-3105-1550-FC 1550±20nm 700 100 200 20 800 3800 1.3 8 TE
LDX-3209-1550-FC 1550±20nm 1,750 100 250 20 500 6000 1.5 8 TE
LDX-3309-1550-FC 1550±20nm 2,450 100 250 20 500 9000 1.5 9 TE
LDX-3110-1550-FC 1550±20nm 840 100 250 20 800 5500 1.2 8 TE
LDX-3210-1550-FC 1550±20nm 1,400 100 250 20 800 9000 1.2 8 TE
LDX-3518-1550-FC 1550±20nm 3,500 200 N/A 20 800 14000 1.3 8 TE
LDX-2815-1620-FC 1620±20nm 560 200 300 20 900 5100 1.1 6 TE
LDX-3110-1850-FC 1850±30nm 700 100 250 20 400 5000 1.2 8 TE



inquiry_button

Diodes arrays

Conductively cooled laser diodes. Beam collimation is available on request.

The Standard Package is the C-mount. Other Packages are available at additional cost (see list in the PDF above, and corresponding pictures in the Package chapter).

   LDX Red Bar   LDX CS Package

  • 660-1064nm:
Part Number Wavelength(nm) Output Power(mW) Emitter Size (um) Operating Temp (°C) Threshold Current (mA) Typ. Operating Current(mA) Typ. OperatingVoltage(V) Typ. Beam Divergence (FWHM) Spectral Width (°) FWHM Polarization
θ// (°) θ٣ (°)
Diode Arrays (Most wavelengths are also available as bars, here are some examples)
LDX-4119-660 660±5nm 10 100×19 15 9400 21000 2.1 7 40 1 TE
LDX-4119-670 670±5nm 10 100×19 15 9400 21000 2.1 7 40 1 TE
LDX-4119-680 680±3nm 12 150×19 15 9000 24000 2.5 7 40 1 TE
LDX-4119-690 690±3nm 12 150×19 15 6500 22000 2.3 7 36 1 TE
LDX-4219-730 730±5nm 20 150×19 20 12000 28000 1.9 7 26 1 TM
LDX-4224-750 750±5nm 20 100×24 20 12000 28000 1.9 7 26 1 TM
LDX-4219-760 760±5nm 20 150×19 20 12000 28000 1.9 7 26 1 TM
LDX-4319-795 795±5nm 30 150×19 20 10000 28000 1.9 7 26 2 TM
LDX-4424-1064 1064±10nm 40 100×24 20 5000 30000 1.4 7 38 5 TE
LDX-4419-1064 1064±10nm 40 150×19 20 5000 30000 1.4 7 38 5 TE



inquiry_button



Packages (PDF)

packages

C-Mount can be Standard, Medium or Thick.

inquiry_button
